Casting: Lost wax precision investment casting
Material: Corrosion-resistant stainless steel, CF8, CF8M, 316, 316L, 304, etc
Application: Industrial & sanitary pump rotors
Service: Custom OEM, full machining & quality testing
Please contact gina@guokuncasting.com to get the quotation.
Baoding Guokun can manufacture a multitude of pump casting parts, for example, pump housing, pump casing, cast pump body, pump mounting bracket, casting pump impeller, volute casing, pump impeller, pump casing cover, back liner, pump bracket cover, pump vane and all other customized cast pump components for the centrifugal pumps, vertical centrifugal pump, horizontal centrifugal pump, fire hydrant pump, gear pump, lobe pump, piston pump vacuum pump, submersible pumps, electric pumps and water pump.
A High Quality China Foundry！
Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high-quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.
With a monthly capacity of 100,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
The CF8, CF8M, 304, 316 stainless-steel pump impellers are manufactured via lost wax precision casting technology, delivering high dimensional accuracy, smooth surface finish and outstanding corrosion resistance for all types of fluid pump equipment, such as flow pump, sewage pump, irrigation pump, food pump, chemical centrifugal pump, etc
Core Advantages
Lost Wax Precision Casting Craftsmanship
Adopt full lost wax investment casting process, eliminating rough machining defects. Complex curved blade profiles, integrated hub and vane structures are formed in one casting, with minimal post-processing required. The intricate radial fan blade design you see in the picture ensures stable hydraulic performance and balanced rotation during pump operation.
Premium Stainless Steel Material Options
Available in 304, 316, CF8M, CD4MCU and other stainless-steel grades. Excellent resistance to water, weak acid, alkali and salt corrosion, ideal for water pumps, chemical transfer pumps, sewage pumps and food-grade fluid processing pumps. High tensile strength and wear resistance extend service life under continuous high-speed rotation.
Stainless steel has many properties, including corrosion resistance, durability, temperature resistance, recyclability, maintenance, modern appearance, high tensile strength, good ductility and high hardness. The stainless steel can be used in many different industries, such as automotive, aircraft, construction, marine, medical, food, etc.
The common stainless steel grades
| stainless steel alloys | |||||||
| Grades | Chemical Composition | Mechanical Properties | |||||
| C | Cr | Ni | Mo | Tensile Strength MPa | Yield strength Mpa | Elongation % | |
| 304 | ≤0.08 | 18 ~ 20 | 8 ~ 11 | – | ≥520 | ≥205 | ≥45 |
| 304L | ≤0.03 | 18 ~ 20 | 8 ~ 12 | – | ≥480 | ≥175 | ≥45 |
| 316 | ≤0.08 | 16 ~ 18 | 10 ~ 14 | 2 ~ 3 | ≥520 | ≥205 | ≥45 |
| 316L | ≤0.03 | 16 ~ 18 | 10 ~ 14 | 2 ~ 3 | ≥480 | ≥175 | ≥45 |
| 410 | ≤0.12 | 11.5 ~ 13.5 | ≤0.75 | – | ≥440 | ≥205 | ≥20 |
| 430 | ≤0.12 | 16 ~ 18 | ≤0.75 | – | ≥450 | ≥205 | ≥22 |
The most common stainless steel alloy is austenitic stainless steel, particularly Grade 304 and Grade 316, which is a mixture primarily composed of Cr and Ni, offering good corrosion resistance and excellent formability, making them widely used in various applications.
Strict Dimensional & Surface Control
Precision casting tolerances meet ISO casting standards. Smooth as-cast surfaces reduce flow resistance inside pumps, improving pump efficiency and lowering energy consumption. Customizable hub bore sizes, blade quantities and outer diameters to match your pump motor assemblies perfectly.
Wide Industrial Application Scenarios
These stainless-steel cast impellers are widely used in clean water pumps, industrial chemical pumps, wastewater treatment pumps, agricultural irrigation pumps, and food & beverage processing pump systems. The integrated monoblock casting structure guarantees structural rigidity, avoiding blade deformation or fracture under high pressure fluid circulation.
China pump impeller factory
Custom OEM & One-Stop Service
We support custom production based on your drawings, samples or performance requirements. Our factory provides full services including casting, CNC machining, dynamic balancing testing, surface polishing and non-destructive testing (NDT: UT/PT/X-ray) to guarantee reliable pump rotor quality before delivery.
Pump castings, China sand casting foundry
Pump casting, Valve casting, agricultural casting, aircraft casting, railway casting, road casting, motor casting, mining casting, power generation investment casting, Medical casting, marine industry casting
