Ductile iron grout sleeve factory in China

Home Sand Casting Ductile iron grout sleeve factory in China

Ductile iron grout sleeve factory in China

Baoding Guokun, China sand-casting factory, occupies a total area of 30,000 square meters, which have casting foundry workshop, grinding, sandblasting and precision machining shop, laboratory and warehouse. Baoding Guokun has equipped with 4 sets medium-frequency electric furnaces, 15 sets automatic shell core machinery, automatic sand-casting molding line, 7 sets CNC machinery, 20 sets CNC Lathe, and the complete quality inspection devices for mechanical testing and chemical analysis, including tensile strength, hardness tester, metallographic inspection, spectrometer, ultrasonic testing and special testing devices. Before shipping, the quality reports for all inspection will be issued and mailed to our customers. We can offer green sand casting, resin sand casting, precoated sand casting, shell mold casting process for your ductile iron grout sleeve.

Sand Casting, Iron Casting2025-08-20m24 Tags: grout sleeve

Description

Baoding Guokun, China sand-casting factory, occupies a total area of 30,000 square meters, which have casting foundry workshop, grinding, sandblasting and precision machining shop, laboratory and warehouse. Baoding Guokun has equipped with 4 sets medium-frequency electric furnaces, 15 sets automatic shell core machinery, automatic sand-casting molding line, 7 sets CNC machinery, 20 sets CNC Lathe, and the complete quality inspection devices for mechanical testing and chemical analysis, including tensile strength, hardness tester, metallographic inspection, spectrometer, ultrasonic testing and special testing devices. Before shipping, the quality reports for all inspection will be issued and mailed to our customers. We can offer green sand casting, resin sand casting, precoated sand casting, shell mold casting process for your ductile iron grout sleeve.

Ductile iron grout sleeve sand casting factory in China

Ductile iron grout sleeve sand casting factory in China

Details of grout sleeve produced by our factory

Part name Grout sleeve
Type Full grout sleeve & half grout sleeve
Material Ductile ironGGG50, GGG60,  QT500, QT600, EN-GJL-500-7, with the spheroidization rate is more than 90%
Process Sand casting and machining
Size The grouting sleeve is widely used in the continuation of Φ12-Φ40 steel bars in construction, roads, bridges and other projects. And the grout sleeve’s dimensions can be customized to fit specific requirements.
Specification Can meet the requirements of “Grouting sleeve for steel connection” and “Technical specification for Mechanical connection of steel bars”, such as JG/T 398-2019, JGJ355, ACI 318, etc.
Advantages Ductile iron offer excellent strength and durability
Easy installation: The grout sleeve is designed for easy installation, ensuring a quick and efficient process.
Reliable performance
Low maintenance
Competitive prices

What is sand casting or shell mold casting process?

The process of Baoding Guokun sand casting involves several steps after producing a professional tool or mold, including:

No. Steps Details
1 Pattern Creation A two-piece metal pattern is created in the shape of the desired part, typically from iron, aluminum or wooden material.For a single casting or small batches of castings, we prefer to produce to use the wooden material to manufacture the mold to save money for customers.For other sand casting parts in large quantity, we prefer to use aluminum or iron to improve the mold’s service life.
2 Mold creation & assembly The two shell halves are joined together and securely clamped to form the complete shell mold. If any cores are required, they are inserted prior to closing the mold. The shell mold is then placed into a flask and supported by a backing material.
3 Pouring The mold is securely clamped together while the molten metal is poured from a ladle into the gating system and fills the mold cavity.
4 Cooling After the mold has been filled, the molten metal is allowed to cool and solidify into the shape of the final castings.
5 Casting removal After the molten metal has cooled, the mold can be broken and the casting removed. Trimming and cleaning processes are required to remove any excess metal from the feed system and any sand from the mold
6 Machining CNC machining as per customer’s drawings.

The ductile iron sand casting grout sleeve produced by Baoding Guokun is famous for its durability and strength in the local and international precast concrete market. More than 25 years casting experience and professional casting equipment can assure you the competitive prices, high quality and short lead time.

Pump casting, Valve casting, agricultural casting, aircraft casting, railway casting, road casting, motor casting, mining casting, power generation investment casting, Medical casting, marine industry casting

Baoding Guokun Machinery Co., Ltd.

Baoding Guokun Export and Import Trading Co., Ltd

Office Add: 777# Chaoyang South Street, Baoding City, Hebei, 071000, China

Factory Address: Wangdu County, Baoding City, Hebei, 071000, China

Website: www.metalcastingfactory.com

Tel: 86-312-5951319 Fax: 86-312-5951296

Phone: 86-181 3278 9710 (WhatsApp & WeChat)

Email: gina@guokuncasting.com

gina.guokun@gmail.com
