Stainless steel ball valve body

Baoding Guokun, with 25 years casting experience, can produce various stainless steel investment casting for various industries. Lost wax investment casting process can produce complex parts that are near-net shape. The stainless steel lost-wax casting parts manufactured by Baoding Guokun is with complex shapes, tight and accurate tolerances that have a standard of +/-0.005, fine surface finish 125 μin (3.2 μm Ra), minimal machining to reduce time and cost and cost-effective. If you need OEM customized valve castings, such as ball valve body, check valve body, butterfly valve body, valve disc and other valve castings in stainless steel, carbon steel, alloy steel, aluminum, brass, bronze, cast iron, please contact gina@guokuncasting.com to get more information.

Investment Casting, Valve Castings Tags: valve body

Description

Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry. Baoding Guokun has been specialized in the designing and manufacturing of various valve components for ball valve, gate valve, globe valve, butterfly valve, through conduit gate valve, knife gate valve, bellow valve, strainers and flow control components.

What is the common material for valve body?

Valve bodies can be made from a variety of materials, including metals and non-metals, depending on the fluid, pressure, tempreature and other factors. Baoding Guokun can cast the customized valve bodies as per the following metals:

Valve Body material
Cast iron valve body	more suitable for low pressure valves with working temperature between -15~200 °C and nominal pressure no more than PN16.
Ductile iron valve body	Stronger and tougher than gray cast iron valve body, making it more suitable for medium and low pressure valvess with working temperature between –30°C to 350°C and nominal pressure no more than PN40.
Carbon steel valve body	Suitable for water, steam, air, hydrogen, ammonia, nitrogen and petroleum medium. WCB valve body or WCC valve body is suitable for medium and high pressure with working tempearture range of –30°C to 425°C and nominal pressure can reach up to PN420.
Austenitic stainless steel valve body	Suitable for the valve of corrosive medium with working tempeature range of –196°C to 816°C. SS304 and SS316 is durable and resistant to corrosion, making it a good choice for a wide range of applications.
Cast copper alloy valve body	used in valves for oxygen and sea water pipelines, with a working temperature range of –273°C to 200°C.

Baoding Guokun also can produce cast iron valve body, ductile iron valve body, gray iron valve body, bronze valve body, brass valve body, stainless steel valve body, austenitic stainless steel valve body, duplex stainless steel valve body, alloy steel valve body as per your drawings or design. The stainless steel ball valve body is produced by silica sol investment casting process.

What is investment casting process for valve castings?

Baoding Guokun, with 25 years casting experience, can produce various stainless steel investment casting for various industries. Lost wax investment casting process can produce complex parts that are near-net shape. The stainless steel lost-wax casting parts manufactured by Baoding Guokun is with complex shapes, tight and accurate tolerances that have a standard of +/-0.005, fine surface finish 125 μin (3.2 μm Ra), minimal machining to reduce time and cost and cost-effective. Investment casting is an industrial metal casting process based on lost-wax precision casting, generally used for producing complex-shaped metal components that require tighter tolerances, thinner walls and better surface finish than other sand cast parts. Baoding Guokun can produce various investment casting parts in low-carbon steel, mild steel, alloy steel, stainless steel for pump, valve, agriculture, railway, road, forklift, tillage, mining, automotive, medical, food, and aircraft, etc.

China investment casting pump parts company

How investment casting process works?

Baoding Guokun Investment casting stainless steel valve body’s steps:

No.	Steps	Details
1	Patterns Makings	Creating a wax mold of the desired stainless steel pump impellers, and then adding sprues to the wax model to create a tree-like structure.
2	Shell Building	Coating the wax pattern with a layer of fire-resistant paint, and then to be sprinkled with sand, so after a period of hardening, the surface will form a layer of fire-resistant thin shell.
3	Dewaxing	Removing the wax, the shell is placed into an oven, melting the wax so that it can run out of the shell.
4	Pouring	Pouring the molten stainless steel into the shell, and waiting for solidification under room temperature.
5	Post treatment	After cooling, knock the shell and cut the sprue gate by grinding machinery to achieve net shape impeller castings. Then shot blasting to move mill scales to assure the smooth casting surface.
6	Machining	CNC Machining & Balancing

Stainless steel investment casting ball valve body:

Stainless steel is a type of low-carbon steel that is resistant to corrosion and rusting. It is made from iron, chromium, and other elements, such as nickel, carbon, molybdenum, and nitrogen. The chromium content in stainless steel is at least 10.5%, which creates a chromium oxide layer on the surface that protects the material from further oxidation.

Stainless steel has many properties, including corrosion resistance, durability, temperature resistance, recyclability, maintenance, modern appearance, high tensile strength, good ductility and high hardness. The stainless steel can be used in many different industries, such as automotive, aircraft, construction, marine, medical, food, etc.

stainless steel alloys
Gr.	Chemical Composition				Mechanical Properties
Gr.	C	Cr	Ni	Mo	Tensile Strength MPa	Yield strength Mpa	Elongation%
304	≤0.08	18 ~ 20	8 ~ 11	–	≥520	≥205	≥45
304L	≤0.03	18 ~ 20	8 ~ 12	–	≥480	≥175	≥45
316	≤0.08	16 ~ 18	10 ~ 14	2 ~ 3	≥520	≥205	≥45
316L	≤0.03	16 ~ 18	10 ~ 14	2 ~ 3	≥480	≥175	≥45
410	≤0.12	11.5 ~ 13.5	≤0.75	–	≥440	≥205	≥20
430	≤0.12	16 ~ 18	≤0.75	–	≥450	≥205	≥22

A High Quality China Foundry！

With a monthly capacity of 10,000kgs and with more than 25 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
