Reduction spur gear box housing

Metal: ASTM A48 class 20, class 25, class 30, class 35, class 40, class 45, class 50, class 55, class 60.

Metal casting: clay sand casting, resin sand casting, shell molding casting

Casting tolerance: ISO 8062 CT9-CT12

Casting surface roughness: 1.6μm Ra ~ 6.3μm Ra

Weight controlled: 0.5~10,000 kgs

Please note that the accuracy level of sand castings is not only affected by the mold process and material quality, but also by the selected metal materials, pouring temperature, and cooling rate. Please contact gina@guokuncasting.com to get a quotation

Agricultural Castings Tags: gearbox

Description

Grey cast iron gearbox cases or housing

Baoding Guokun Machinery Co., Ltd and Baoding Guokun Export and Import Trading Co., Ltd are located in Baoding city, Hebei province, China. Our sand-casting factory occupies a total area of 30,000 square meters, which have casting foundry workshop, grinding, sandblasting and precision machining shop, laboratory and warehouse. Baoding Guokun has equipped with 4 sets medium-frequency electric furnaces, 15 sets automatic shell core machinery, automatic sand-casting molding line, 7 sets CNC machinery, 20 sets CNC Lathe, and the complete quality inspection devices for mechanical testing and chemical analysis, including tensile strength, hardness tester, metallographic inspection, spectrometer, ultrasonic testing and special testing devices. Before shipping, the quality reports for all inspection will be issued and mailed to our customers. We can offer green sand casting, resin sand casting, precoated sand casting, shell mold casting process for your OEM casting parts.

sand casting workshop

Cast gray iron is a type of cast iron which made up of carbon, silicon, and manganese. The grey iron is the most common cast iron and is named for its gray color when it fractures due to the presence of graphite flakes. Due to high thermal conductivity, excellent vibration damping, good corrosion resistance, and easy to machine, the cast gray iron is mainly used for automotive, construction, cookware, pump, valve, truck, agriculture, mining, such as gearbox housing, pump shell, valve body, motor housing, etc.

Gray cast iron: ASTM A48 Standard Specification for Gray Iron Castings

This specification covers gray iron castings intended for general engineering use where tensile strength is a major consideration. Castings are classified on the basis of the tensile strength of the iron in separately cast test bars. The casting surface shall be free of adhering sand, scale, cracks and hot tears, as determined by visual examination.

Baoding Guokun can use grey cast iron to produce the following products:

Pump casting: Pump casing, pump housing, pump shell, pump back liner, pump cover plate, hydraulic pump parts and other customized pump replacement parts.

Valve casting: Valve body, valve seating, industrial valve fittings and other valve casting components.

Automotive casting: engine blocks, brake systems, brake disc, clutch plates, cylinder liners, and positions, etc.

Agricultural machinery casting parts: plow shares, tillers, irrigation system components, and other tractor casting parts.

Baoding Guokun casting factory can offer you green sand-casting process, resin sand casting process or shell mold casting process.

The process of Baoding Guokun sand casting involves several steps after producing a professional tool or mold, including:

Ductile iron sand casting technique steps

pouring of shell mold casting in Baoding Guokun sand casting factory

A High Quality China Foundry！

Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.

With a monthly capacity of 10,000kgs and with more than 25 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
