[caption id="attachment_458" align="alignnone" width="600"]
cast iron motor bearing cover[/caption]
[caption id="attachment_459" align="alignnone" width="600"]
electrical motor end cover[/caption]
Part Name: Motor castings, motor end cover
Metal: Cast steel, cast iron, aluminum alloy motor castings, ASTM A 356, ASTM A216, ASTM A48, etc.
Process: Lost foam casting, sand casting or investment casting process and machining
Baoding Guokun can produce motor casting and engine casting parts, motor shell, end bracket, frame, cooling fan, end bracket, bearing housing and other custom motor casting as per your drawings. Please contact gina@guokuncasting.com to get a quote.
Engine and motor castings manufacturer!
Baoding Guokun is a 25 years’ experience casting factory in sand molding process and investment casting process for motor casting and engine casting parts, motor shell, end bracket, frame, cooling fan, end bracket, bearing housing and other custom motor casting in cast iron, cast steel and aluminum alloys.
The metal casting process for motor castings we can offered is as follows:
|
No. |
Investment Casting | Sand Casting | Lost Foam Casting |
Precision Machining |
|
Process |
Investment casting, also named lost-wax casting, making parts from molten metal. | Sand casting, the most widely used casting process, utilizes expendable sand molds to form complex, metal parts that can be made of nearly any alloy | Lost foam casting is a metal casting process for creating complex metal parts that uses a foam pattern instead of wax. | Precision machining from the tubes, bars, blocks to get the required shapes. |
|
Metal |
steel, brass, copper and bronze | steel, brass, copper and copper, cast iron | Steel, iron and Aluminum alloy | steel, brass, copper and bronze, aluminum, etc |
|
Weight |
Max. 500kgs | Max. 20,000kgs | Max. 100 kgs |
Max. 10,000 kgs |
| Tolerance | CT4-7 | CT9-CT12 | as per drawings |
as per drawings |
| Advantage | Complex structure and high production rate | Can produce complex structure | Dimensional accuracy, reduced machining, cost-effective, no parting line. |
high precision |
Metal for motor castings:
Ductile iron motor casting: ASTM A536 Gr.65-45-12, Gr.60-40-18, Gr.80-55-06; GGG40, GGG50, GGG60. JIS-FCD40, FCD50, FCD60, QT450-12, etc
Gray Iron motor castings: ASTM A48 class20, calss30, class 35, class 40, DIN 1691 GG20, GG25, GG30, JIS-FC10, FC15, FC25, HT200, HT250, HT300, etc.
Stainless steel motor castings: 316, 304, CF8, CF8M, 1.4308, 1.4408, etc.
Alloy steel motor castings: DIN-GS-40Mn5, GS-20Mn5, 35CrMo4, ASTM A487, Grade 4 castings, etc.
Carbon steel motor castings: ASTM A216 Gr. WCB, WCC, WCA, 1.0446, 1.0416, etc.
Aluminum alloy motor castings: ASTM A356, A380, ADC10, ADC12, etc.
A High Quality China Foundry！
Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.
With a montly capacity of 10,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
Baoding Guokun can produce various Motor castings, engine castings, motor casting company, motor casting China, motor cast, motor casting, motor body casting, engine block casting, motor block casting, foundry motor company, cast iron motor casting manufacturer, motor part company, stainless steel motor casting, cast iron motor castings, ductile iron motor castings, aluminum alloy motor castings, pump impeller and other pump parts.
