Product name: Cast steel levis and yoke ends
Metal: Cast steel, carbon steel, alloy steel or stainless steel castings 304 or 316
Surface: Sand blasting with anti-rust oil
Metal Process: Lost wax investment casting, silica sol casting techniques
Packaging: Wooden boxes or as per your orders.
FOB port: Tianjin
Lead time: 15~45 days
Weight controlled: 0.1~50 kg.
Casting accuracy: ISO 8062 CT4-CT7
Contact information: Gina@guokuncasting.com or 86-18132789710 (WhatsApp & WeChat)
Cast steel clevis and yoke ends
Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, hydraulic cylinder, truck, automobile, pump, valve, motor, pipe fittings and gear industry.
With a monthly capacity of 10,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
What’s Yoke Ends?
Yoke ends, also called a clevis yoke or clevis ends, are yoke fittings usually assembled to the end of a rod, pipe or tube. Once it is secured, the yoke is attached with a clevis pin to mounting point. Baoding Guokun can manufacture the yoke clevis ends in carbon steel, SAE J493 or 1045 as per your drawings. Most customer would like to buy the forged yoke end becuase the forging clevis yoke are significantly stronger due to the steel’s improved grain structure from the forging process. And compared with the cast yoke end, the drop forged yoke clevis can withstand repeated loading cycles without failling as easily as casting yoke hardware. But when strength requirements are less demanding and cost is the primary concern, you also can choose the casted yoke end produced by Baoding Guokun.
Cast steel yoke end’s process:
Investment casting is an industrial metal casting process based on lost-wax precision casting, generally used for producing complex-shaped metal components that require tighter tolerances, thinner walls and better surface finish than other sand cast parts. Baoding Guokun can produce various investment casting parts in low-carbon steel, mild steel, alloy steel, stainless steel for pump, valve, agriculture, railway, road, forklift, tillage, mining, automotive, medical, food, and aircraft, etc.
Drop forged clevis process:
Drop forging is a highly valued metal forging process that uses a pair of impression dies and a heavy hammer to form and compress metal bars or billets into complex shapes. The steel forged clevis end yoke are with high density, good mechanical properties and wear resistance, compared with casting rod end yoke.
Baoding Guokun’s drop forging process
A High Quality China Foundry！
Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.
With a montly capacity of 10,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
Pump casting, Valve casting, agricultural casting, aircraft casting, railway casting, road casting, motor casting, mining casting, power generation investment casting, Medical casting, marine industry casting
