Cast Iron Pump Impeller

Home Iron Casting Cast Iron Pump Impeller

Cast Iron Pump Impeller

Name: Semi-closed pump impeller or semi-open pump impeller

Material: Cast iron, grey iron ASTM A48 class 30

Casting: Resin sand casting or clay sand casting process

Application: Grey iron pump impellers are generally used in small, low-cost pumps for water supply drainage, irrigation or industrial application. Cast iron impellers are with good castability, machinability and vibration damping properties.

If you need gray cast iron pump impellers, please feel free to contact gina@guokuncasting.com to get the prices.

Iron Casting, Pump Castings Tags:

Description

The pump impeller is the rotating component in the pump that directly transfers the energy from the motor into the fluid being pumped. Pump impellers are classified as one of three types: Open impeller, semi-open impeller, or closed impeller. Their classification is based on whether they have a protective shroud or not.

pumpimpeller

Impellers are made from a variety of materials, including stainless steel, cast iron, bronze, aluminum, austenitic stainless steel, titanium, etc. When you choose the suitable material for pump impeller, you should think about the following several factors, strength, fluid compatibility, abrasion resistance, environmental conditions, type of liquid being pumped, casting and machining properties, etc.

Baoding Guokun can offer you the most suitable material as per your pump’s requirements. And with 25 years casting experience, we can produce the custom pump impellers with the suitable cast metal and casting process.

Product

 Material

Casting process

Pump impeller

 300 series Stainless steel, 400 series stainless steel, low-carbon steel, alloy steel, mild steel, cast steel Investment casting (lost wax casting)

Cast iron, ductile iron, grey iron

Sand casting, lost foam casting
Bronze, Nickel-aluminum bronze, brass, aluminum, etc.

Sand casting or gravity casting for aluminum pump impeller

Cast iron pump impeller

Cast iron pump impellers are generally used in small, low-cost pumps for water supply drainage, irrigation or industrial application. Cast iron impellers are with good castability, machinability and vibration damping properties.

Compared with bronze impeller or stainless-steel pump impeller, grey cast iron impellers are less resistant to corrosion, erosion and cavitation. Because cast iron will always rust in water environments, and crevice corrosion can occur in casting components. But cast-iron impellers are robust and cost-effective, ideal for handling abrasive fluids in applications like mining, construction, and agriculture.

Application of cast iron pump impeller

1.      Water supply and drainage Cast iron impellers are used in pumps that transfer clean water and similar liquids in factories, mines, cities, and for fire fighting

2.      Irrigation

Cast iron impellers are used in irrigation pumps.
3.      Industrial applications

Cast iron impellers are used in industrial applications, such as in the food and beverage, pharmaceutical, and cosmetics production industries.

A cast iron impeller is typically made from gray iron as it is the most common cast iron due to its good castability, machinability, and vibration damping properties, although in situations requiring higher strength and impact resistance, ductile iron might be used instead.

Cast Iron pump impeller’s material

Gray iron pump impellers

 ASTM A48 Standard Specification for Gray Iron Castings, for example, ASTM A48 Class 30, ASTM A48M class 35, ASTM A48 class 40, etc. More brittle but has better vibration damping and is generally cheaper than ductile iron.
Ductile iron pump impellers ASTM A536 Standard Specification for Ductile Iron Castings. ASTM A536 grade 65-45-12, ASTM A536 Grade 80-55-06, ASTM Gade 60-40-18, etc

Offers greater strength and ductility, making it suitable for applications with higher impact loads.

Casting process of cast iron pump impellers:

Clay sand casting

Resin sand casting

Shell mold casting

clay sand casting

shell mold casting

Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high-quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.

With a monthly capacity of 10,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.

Ours Mission

It is our mission to provide flexible, cost-effective solutions for our customers on time, every time while maintaining the highest standards of quality.
