Cast iron motor housing end cover

Home Iron Casting Cast iron motor housing end cover

Cast iron motor housing end cover

Part name: electric motor bearing end shield, front end shield, rear end shield, motor housing hub end cover, motor end caps, motor housing end cover

Metal: cast gray iron motor bearing covers ASTM A48 Class 20, calss 35

Process: Sand molding casting process

Weight controlled: 1-500 kgs

Surface treatment: Anti-rust oil or painting

Baoding Guokun can produce various electrical motor bearing covers in grey iron, ductile iron, cast iron as per your drawings. ASTM A48, ASTM A536 is normal cast iron used for motor castings. If similar need, please contact gina@guokuncasting.com to get a quotation.

Iron Casting, Motor Castings Tags: ,

Description

Engine and motor castings manufacturer!

Baoding Guokun is a 25 years’ experience casting factory in sand molding process and investment casting process for motor casting and engine casting parts, motor shell, end bracket, frame, cooling fan, end bracket, bearing housing, motor housing end cap, motor end cover, motor housing hub end cover, motor end bracket, electric mold frame, motor end bell, motor base, motor fan cover, cooling fan, cast iron frame, end bracket, bearing housing, rear end shield, front end shield and other custom motor casting in cast iron, cast steel and aluminum alloys.

motor end cover casting factory

motor end cover casting factory

What is motor bearing cover or motor end shield?

The casting motor bearing rear end shield and front end shield is an important and protective motor casting replacment parts that seals and shields the bearings within an electric motor, preventing contaminants like dust and moisture from entering while helping to retain lubrication, thus extending the bearing’s working life and improve the motor performance.

What’s metal casting process for cast iron motor end bracket?

Sand casting process is an industrial metal casting process that involves creating a mold from sand and pouring molten metal into it, generally used to cast the shaped parts of nearly any design, including large parts and those with internal passages. Baoding Guokun can produce various sand cast parts in cast iron, ductile iron, gray iron, low-carbon steel, mild steel, alloy steel for pump, valve, agriculture, railway, road, forklift, tillage, mining, automotive, medical, food, and aircraft, electric motor parts, etc.

The process of Baoding Guokun sand casting involves several steps after producing a professional tool or mold, including:

No. Steps Details
1 Pattern Creation A two-piece metal pattern is created in the shape of the desired part, typically from iron, aluminum or wooden material.For a single casting or small batches of castings, we prefer to produce to use the wooden material to manufacture the mold to save money for customers.For other sand casting parts in large quantity, we prefer to use aluminum or iron to improve the mold’s service life.
2 Mold creation The two shell halves are joined together and securely clamped to form the complete shell mold. If any cores are required, they are inserted prior to closing the mold. The shell mold is then placed into a flask and supported by a backing material.
3 Pouring The mold is securely clamped together while the molten metal is poured from a ladle into the gating system and fills the mold cavity.
4 Cooling After the mold has been filled, the molten metal is allowed to cool and solidify into the shape of the final castings.
5 Casting removal After the molten metal has cooled, the mold can be broken and the casting removed. Trimming and cleaning processes are required to remove any excess metal from the feed system and any sand from the mold
6 Machining  Machining as per drawings
Baoding Guokun sand casting pouring process

Baoding Guokun sand casting pouring process

What’s material for customized electric motor end cover?

Ductile iron motor bearing cover: ASTM A536 Gr.65-45-12, Gr.60-40-18, Gr.80-55-06; GGG40, GGG50, GGG60. JIS-FCD40, FCD50, FCD60, QT450-12, etc

Gray Iron motor end cover: ASTM A48 class20, calss30, class 35, class 40, DIN 1691 GG20, GG25, GG30, JIS-FC10, FC15, FC25, HT200, HT250, HT300, etc.

Stainless steel motor end cover: 316, 304, CF8, CF8M, 1.4308, 1.4408, etc.

Alloy steel motor end covers: DIN-GS-40Mn5, GS-20Mn5, 35CrMo4, ASTM A487, Grade 4 castings, etc.

Carbon steel motorend covers: ASTM A216 Gr. WCB, WCC, WCA, 1.0446, 1.0416, etc.

Aluminum alloy motor end covers: ASTM A356, A380, ADC10, ADC12, etc.

Baoding Guokun can produce various Motor castings, engine castings, motor casting company, motor casting China, motor cast, motor casting and engine casting parts, motor shell, end bracket, frame, cooling fan, end bracket, bearing housing, motor housing end cap, motor end cover, motor housing hub end cover, motor end bracket, electric mold frame, motor end bell, motor base, motor fan cover, cooling fan, cast iron frame, end bracket, bearing housing, rear end shield, front end shield, pump impeller and other pump parts.

Gray iron casting motor casing, motor housing produced by Baoding Guokun. If you would like cast iron motor casing, aluminum alloy motor housing, please feel free to contact gina@guokuncasting.com to get the quotation.

A High Quality China Foundry！

Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry.

With a monthly capacity of 10,000kgs and with more than 25 years of experience ensure the short delivery and the highest valued iron & steel casting parts.
